GNSS receiver GM SMART for parallel driving, agronavigation 10 Hz

Brand: geometer
Article: GMSMP
Rating:
4.9
Availability:
In stock
Quantity:
+
26 325 грн
Shipping methods

Airmail with tracking

Other transport services

Express shipping

Pickup

Payment methods

PayPal

Bank account payment

Privatbank

Liqpay

THERE ARE NO ANALOGUES IN ITS PRICE SEGMENT AND ACCURACY IN UKRAINE AND CIS COUNTRIES!

GNSS receiver GM SMART - a new generation receiver for working with any navigation programs and the ability to increase accuracy to 1 cm.

The receiver is designed on the basis of the latest one-frequency OEM board of professional level. It has 200 channels for working with all available satellite systems: GPS, GLONASS, BEIDOU, SBAS.

The GM SMART receiver has a built-in software DP filter designed for use with parallel driving systems. Thanks to the DP filter, high accuracy of relative coordinates during parallel driving is provided. When working with the GM Smart receiver, the geometer and geotrack application automatically adjusts the receiver to perform its tasks: smoothing or RTK mode is turned on. In smoothing mode, you get a stable coordinate during work, without accidental throws in different directions.

The GNSS GM SMART receiver can be upgraded to the RTK (RTK L1) level and operated from its own base station or from network corrections over the Internet. Since this receiver is based on a single frequency board, the distance from the base station when working with a single frequency RTK should not exceed 8 km. It is possible to modify the receiver with the radio modem LoRa, as well as translate corrections in the local network of the enterprise.

GNSS GM SMART receiver is ideal for any operation:

 accurate measurement of the boundaries of fields and sections of any size and shape,

 land surveying,

 path to the point,

 soil preparation,

 sowing works,

 spreading fertilizers,

 spraying,

 accurate mapping.

CHARACTERISTICS

  • Monoblock: receiver with antenna
  • Mount: magnetic holder
  • Channels: 200 channels, L1, GPS/GLONASS/GALILEO/BEIDOU
  • Operation modes: smoothing mode, RTK
  • Frequency: 10 Hz (position update 10 times per second)
  • Diameter: 17 cm

The receiver will work perfectly with any mapping software, as well as with programs for measuring areas, distances, for parallel driving. We invite you to visit the office of our company for demonstrations.




  • Diameter 170 мм
  • Country of manufacture Ukraine
  • Body IP67 Standard Protection
  • Frequency 10 Hz
  • Mount Magnetic holder
  • Interfaces Bluetooth
  • Number of channels 200 channels, L1, GPS / GLONASS / GALILEO / BEIDOU
  • Correction filter DP-Filter
